535/1



2¼ hours





UGANDA NATIONAL EXAMINATION BOARD

Uganda Certificate of Education

PHYSICS

Paper 1

Time: 2¼ hours





SECTION A : (40 MARKS)

Answer all questions in this section.

1.  The most suitable instrument for measuring the outer diameter of a test tube is

 A.  a ruler. B.  a tape measure.

ecolebooks.com

 C.  vernier callipers. D.  a micrometer screw gauge.

Image From EcoleBooks.com

2.  An isotope of a nuclide has



 A.  18 protons and 17 neutrons. B.  17 electrons and 18 neutrons.

 C.  17 protons and 20 neutrons. D.  18 protons and 18 neutrons.



3. Which of the following is NOT an effect of an electric current ?

 A.  Electrolysis.  B.  Magnetic effect.

 C.  Heating effect.  D.  Radioactivity.



4. The rate of evaporation of a liquid increases when

 (i)  temperature increases.

 (ii)  pressure increases.

 (iii)  its surface area increases.

 A.  (i) and (ii) only. B.  (i) and (iii) only.

 C.  (ii) and (iii) only. D.  (i), (ii) and (iii).



5. The slope of a velocity-time graph is the

 A.  speed of the body. B.  velocity of the body.

 C.  acceleration of the body. D.  distance travelled by the body.



6.  Which one of the following objects can be charged by friction ?

 A.  Safety pin.  B.  Copper plate.

 C.  Razor blade.  D.  Plastic ruler.



7. Which of the following works with a direct current only ?

 A.  Electroplating.  B.  Electric lamp.

 C.  Transformer.  D.  Electric bell.



8.  A ray of light travelling from a dense to a denser medium is

 A.  refracted towards the normal.

 B.  refracted away from the normal.

 C.  always reflected back to the same medium.

 D.  always transmitted without being reflected.



9.  A car accelerates from 4.0 ms – 1 to 20.0 ms – 1 in 8.0 s. How far does it travel in this time?

 A.  32m. B.  96m.

 C.  128m. D.  160m.



10.  Radiation in a thermos flask is minimised by

 A.  cork. B.  vacuum.

 C.  felt pad.  D.  silvered glass walls.



11.  A mass of 500 g produces an extension of 10 cm in a spring. Find the force that will produce an extension of 25 cm.

 A.  0.5N. B.  12.5 N.

 C.  50.0 N. D.  200.0 N.



12.  Which of the following is best conductor of heat?

 A.  Silver. B.  Iron.

C.  Copper.  D.  Aluminium.



13.  Calculate the power wasted as heat in a cable of resistance 0.5 Ω, when it transmits 2 kW at 100 V.  A.  800 W.  B.  200 W.

 C.  100W. D.  50 W.



14.  The image formed in a plane mirror is

(i)  the same distance behind as the object is infront.

(ii)  totally inverted.

(iii)  magnified and virtual.

 A.  (i) and (ii) only. B.  (i) and (iii) only.

 C.  (ii) and (iii) only. D. (i), (ii) and (iii).



15.  1 lot water pipes are designed with bends in them in order to

 A.  reduce the speed of water. B.  give the pipe more rigidity.

 C.  allow for pressure changes. D.  allow for expansion of the pipe.



16.  Which of the following equations represents a nuclear process in which an a-particle is emitted ?



Image From EcoleBooks.comImage From EcoleBooks.com

  1. B.



Image From EcoleBooks.comImage From EcoleBooks.com

 C. D.



17.  The possible energy transfer in an electric bulb is

 A.  light energy to heat energy.

 B.  heat energy to electrical energy.

 C.  electrical energy to light energy.

 D.  light energy to electrical energy.

Image From EcoleBooks.com18.

















 Figure 1 shows magnetic field lines between two magnetic poles.

 The poles marked P, Q, X and Y are respectively

 A.  north, south, south and north. B.  south, north, north and south.

 C.  north, north, south and north. D.  south, south, north and south.



19.  A body has a constant velocity when

 (i)  acceleration is increasing.

 (ii)  it is moving in a straight line.

 (iii)  the net force on the body is zero.



 A.  (iii) only, B.  (i) and (ii) only.

 C.  (i) and (iii) only.  D.  (ii) and (iii) only.



20.  Light travelling in air is incident on a medium at an angle of 60°.

 Find the refractive index, if the angle, of refraction is 30 .

 A.  0.50. B.  0.58.

 C.  1.73. D.  2.00.



21.  The recoil velocity of a gun will depend on:

(i)  mass of the shell.

(ii)  muzzle velocity of shell.

(iii)  muzzle diameter of the gun.

(iv)  mass of the gun.

 A.  (i) only. B.  (iii) only.

 C.  (ii) and (iii) only.  D.  (i) , (ii) and (iv) only.



22.  A 5 kg mass falling steadily at 0.8 ms”1 is used to drive a dynamo. If the dynamo’s output power is 12 W, find the efficiency of the system.

 A.  3.0%. B.  3.3%.

 C.  30.0%. D.  33.3%.



23.  The principle of conservation of energy states that

 A. energy is the ability to do work.

 B. energy is composed of kinetic and potential energy.

 C. energy will always be converted from one form to another.

 D. energy cannot be created or destroyed but it can be changed from one form into another.



24. When oil of volume 6 ×10 – 3 cm 3is dropped on a clean water surface, it forms a circular patch of one molecule of diameter 2 cm. Find the thickness of oil.

 A.  4.77 × 10– 4 cm.  B.  14.32 × 10– 4 cm

 C.  1.91 × 10– 3 cm.  D.  5.24 × 102 cm



25.  The X and Y – plates in a cathode ray oscilloscope make up the

A.  electron gun. B. deflection system.

 C.  focussing system.  D. accelerating system.



26.  An ‘echo sounder’ in a boat emits a pulse of sound which returns 0.2 s later, after reflection from the sea – bed. If sound travels at 1500 ms – 1 in sea water, how deep is the water ?

 A.  7,500 m. B.  600m.

 C.  300 m. D.  150m.



27.  Cathode rays are

 A.  electromagnetic waves.

 B.  streams of X
rays.

 C.  protons emitted by a hot cathode.

 D.  streams of electrons moving at high speed.



Image From EcoleBooks.com28.



















Fig. 2

 Figure 2 shows two cells each of e.m.f 4.5 volts and internal resistance 0.5 Ω, connected to a 2 Ω resistor. What is the ammeter reading ?

 A.  1.5 A. B.  2.0 A.

 C.  4.0 A. D.  9.0 A.



29.  Gas leaking from a cylinder, at one corner of a room reaches another comer by way of

 A.  diffusion. B.  evaporation.

 C.  Brownian motion.  D.  osmosis.



30.  A man takes one minute to lift 4 bags of sugar each of weight 50 N through a height of

 1.5 m. Calculate the power expended.

 A.  1.25W. B.  5.00 W.

 C.  75.00 W. D.  300.00 W.

31.  The wavelength of a progressive transverse wave is defined as the

 A.  height of a crest.

 B.  distance between a trough and a crest.

 C.  distance between successive crests.

 D.  distance between any two troughs.



32.  A current of 6A flows for 2 hours in a circuit. Calculate the quantity of electricity that flows in this time.

 A.  3 C. B.  12 C.

 C.  720 C. D.  43200 C.



33.  The strength of a material is its ability to resist

(i)  compression.

(ii)  shearing forces.

(iii)  change in size or shape.



 A.  (i) only. B.  (ii) only.

 C.  (i) and (ii) only.  D.  (i), (ii) and (iii).



Image From EcoleBooks.com







 Two forces of 15 N and 35 N act on a block placed on a smooth table as shown in Figure 3. Find the resultant force on the block.



 A.  20N. B.  50N.

 C.  525 N. D.  1000 N.



35.  A stationary wave is formed when two waves of

 A.  equal amplitude and frequency travel along the same path in the same direction.

 B.  equal amplitude and frequency travel perpendicularly to one another .

 C.  equal amplitude and frequency travel along the same path but in opposite directions.

 D.  different frequencies travel along the same path but in opposite directions.



36. The rate at which electric charge flows past a point in a circuit is measured in

 A.  watts. B. volts.

 C. amperes. D.  coulombs.



37.  The frequency of a vibrating string depends on

 A.  pitch. B.  length.

 C.  medium. D.  amplitude.



38.  A car of mass 500 kg accelerates steadily from rest to 40 ms – 1 in 10s. Calculate the force that produces this acceleration.

A.  20,000 N. B.  5,000 N.

 C.  2,000 N. D.  125N.



39.  Which of the following gives the difference between α – particles and β – particles ?

 A.  The charge of an α – particle is +2 while that of the β – particle is –1.

 B.  An α – particle is an electron while the β – particle is a helium atom.

 C.  β –particles are more ionising than α – particles.

 D.  β –particles are heavier than α – particles.



40.  It is easier to use a claw hammer to remove a nail from a piece of wood if the handle is longer because the

 A. effort applied becomes bigger.

 B.  turning effect becomes bigger

 C.  anticlockwise moments will balance clockwise moments.

 D.  fulcrum is between the effort and the load.



SECTION B : (40 MARKS)

Answer all questions in this section. All working must be clearly shown in the spaces provided.



41.  (a)  What is meant by boiling point of a liquid?  (01 mark)



 ………………………………………………………………………………………………………………………………

 ………………………………………………………………………………………………………………………………

 ………………………………………………………………………………………………………………………………

 (b)  Why is cooking faster with a pressure cooker? (01 mark)

 ………………………………………………………………………………………………………………………………

 ………………………………………………………………………………………………………………………………

 ………………………………………………………………………………………………………………………………



(c) State two differences between boiling and evaporation. (02 marks)

 ………………………………………………………………………………………………………………………………

 ………………………………………………………………………………………………………………………………

 ………………………………………………………………………………………………………………………………

41.  (a) Define work.
(01 mark)

 ………………………………………………………………………………………………………………………………

 ………………………………………………………………………………………………………………………………

 ………………………………………………………………………………………………………………………………

(b) A body is raised above the ground and then released. State the subsequent energy changes that occured. (03 marks]

43. (a) State one factor which affects the magnitude of the force on current -carrying conductor in a magnetic field. (01 mark]

(b)

N

B

Fig. 4

Figure 4 shows a wire placed in a uniform magnetic field. If the force acting on the wire is into the paper,

(i) indicate on the diagram the direction of the current through the wire. (01 mark)

(ii) explain what happens when the battery terminals connected to wire AB are reversed. (02 marks)



44. (a) What is meant by radioactivity ?

(01 mark]

235 1 236 144 – v 1

(b) U + n —–* U —–*• Ba + ‘Kr + 2 n + eneruv

92 0 92 x 36 0

The equation above shows a reaction which takes place in a nuclear reactor.

I  (i)  Name the reaction shown by the equation. (01 mark}

(ii) Find x and y. (2 marks]



45.  (a)

8N

BOX

12N

Smooth surface

Fig. 5

Figure 5 shows a box of mass 2.0 kc on a smooth surface. If forces

of 12N and SN acts on it, find the acceleration.

(03 marks]

(b) Why does a stone released in space fall?

(01 mark]



46. (a) State the laws of reflection.  (02 marks]

(b)

X-

s\\\\V

Fig. 6

Figure 6 shows two successive parallel wave fronts A and B incident on a straight barrier XY. Complete the diagram to show the reflected wave fronts.  (02 marks]



47.  (a) What is a ductile material ?  (01 mark]

(b) Give two examples of ductile materials. (01 mark)

(c) A load of 12N stretches a spring by 80 mm. Find the weight which produces an extension of

60 mm on the same spring. (02 marks)

48. (a) What is meant by resistance in an electric circuit?
(01 mark)

(b) Three resistors 2Q, 4Q and 3Q are connected in the same circuit.

(i) Draw a diagram to show how they are connected to give

minimum resistance. (01 mark]

(ii) Find the value of the minimum resistance. (02 marks]

49. (a) What is meant by

(i) centre of gravity?

(01 mark]

(ii) moment of a force?

(01 mark}

(b)

1.0 in

FY

Fig. 7

Figure 7 shows a uniform rod of length 4.0 m pivoted at 1.0 m from one end. If the weight of the rod is 120 N, find the force F which keeps the rod horizontal. (02 marks]

50.

Fig. 8

Figure 8 shows a ray of light incident normally on a glass prism in air. The critical angle of the prism is 42°.

(a) Complete the ray diagram to show the path of the light as it emerges from the prism. (02 marks}

(b) Calculate the refractive index of the glass of the prism.

(02 marks)



**********
