AUTO BODY REPAIRS AND SPRAY PAINTING




SCHEME OF EXAMINATION



There will be three papers, Papers 1, 2 and 3 all of which must be taken. Papers 1 and 2 will be a composite paper to be taken at one sitting.



Paper 1:  will consist of forty multiple-choice objective questions all of which are to be answered in 1 hour for 40 marks.



Paper 2:   will consist of five essay questions. Candidates will be required to answer any four in 1½ hours for 60 marks.



Paper 3:  will be a practical test of 3 hours, 10 minutes duration. It will consist of one compulsory question for 100 marks.



A list of materials for the test shall be made available to schools not less

ecolebooks.com

than two weeks before the paper is taken for material procurement and

relevant preparations.






ALTERNATIVE TO PRACTICAL TEST

Alternatively, in the event that materials for the actual practical test cannot be acquired, the Council may consider testing theoretically, candidates’ level of acquisition of the practical skills prescribed in the syllabus. For this alternative test, there will be one question to be answered in 3 hours for 100 marks.













































DETAILED SYLLABUS





1.





Safety rules and regulations in Auto body repairs and













spray painting.

  1. Definition of safety rules and regulations in auto body repairs and spray painting.



1.2. List of rules and regulations and their importance.



1.3 List of safety tools and equipment/machines for auto body repairs.







1.4 Auto body dressing code: personal protective equipment (nose mask, goggles, boots, ear defender, etc).













1.5 Sources of accident (human factors, machinery/equipment and workshop keeping) and their preventions.





















1.6 Factory acts on safety rules and  regulations: 1984 amended  resource conservation recovery  act, environmental protection  agency regulations and  hazardous waste collection and  recycling (solvent recovery  system).















1:3:1 Identification of safety tools and equipment and demonstration of  their usage.



1:4:1 Identification of   dress code and   protective   equipment and   demonstration of

their usage.



1:5:1 Identification of  containers for  hazardous waste.

1:5:2 Demonstration of horse play.

1:5:3 Report faulty machines/

equipment

1:5:4 Demonstration of workshop keeping e.g. cleaning oil and water from the floor with saw dust and dry sand

S/NO.

TOPIC

CONTENT

PRACTICAL

Tools and Equipment

(a) Basic Hand Tools































(b) Spray painting tools and equipment.









(c) Care and maintenance of tools and equipment.



2.1 Types of hand tools. (hammers, dollies, spanner, files, ratchets, body spoons, etc) and their uses.



2.2 Types and uses of power tools

 and  equipment/machines (drilling

 machine, body jack, sanders,  air compressor, shaping  machines, cutting machine, etc).



2.3 Advantages and disadvantages of machines.



2.4 Uses of machines and safety precautions.



2.5 Spray painting tools and equipment (scrapers, brushes, funnels, paint pots, spray gun, spraybody filters, air compressor, oven, spray boot, etc).



2.6 Definition of maintenance and types – predictive, preventive and corrective.



2.7 Manufacturer’s maintenance  guide.



2.8 Maintenance of tools and equipment.



2:1:1 Identification of hand tools and equipment





2:2:1 Identification and demonstration of the use of power tools.











2:4:1 Demonstration of the use of machine.



2:5:1 identification of spray painting tools, equipment and their uses.













2:8:1 Dismantling and assembly of a spray gun

2:8:2 Cleaning of  tools

and equipment

3.

Materials for auto-body repairs and spray painting

(a) Auto-body Repairs materials.































(b) Spray painting

 materials.

3.1 Types of body filler

– plastic filler;

– fibreglass fillers;

– body solder; 30/70 and 40/60.





3.2 Type of body abrasives e.g. sand  papers, (wet and dry);

Sanding disc.





3.3 Type of sealers e.g. rubber

 sealers, seam sealers,  undercoating, etc.



3.4. Rivet pins e.g. pop and solid rivets.







3.5 Types of paints – Enamel paints and lacquers.



– Under coats: surface  primer, putty/body filler, sealers.

– Top coats: lacquers and enamel  paints.



3.6 Manufactures paint guide: paint formula, paint mixing equipment, custom-mix basecolours, paint  labels, colour charts.

3:1:1 Identification of body fillers.









3:2:1 Identification of body abrasives.

.









3:4:1 Demonstration of the use of rivet gun.



3:5:1 Identification of

paints by use of thinner.



3:5:2 Demonstration of the use of under coats.

3:5:3 Demonstration of those of top coats.



3:6:1 Demonstration of  how to mix paints



3:6:2 Identification of   colours using colour chats

4.

Type of metals.

4.1 Ferrous and non ferrous metals – mild teel, cast iron, aluminium, brass, etc.



4.2 Properties of metals – fusibility,

maleability, ductility, weldability, etc.



4.3 Uses of metals on Auto bodies.

4:1:1 Identification of  ferrous and non-  ferrous metals.



4:1:2 Demonstration of properties of metals.

Heat treatment of metals.

5.1 Definition of heat treatment.



5.2 Types and process of heat  treatment e.g. hardening,  annealing, normalizing, case-  hardening and tempering.

5.3 Importance of heat treatment.





5:2:1 Demonstration of heat treatment processes.

6.

Oxy-acetylene welding and equipment.

6.1 Definition of oxy-acetylene welding.



6.2 Safety precautions



6.3 Oxy-acetylene welding equipment.



6.4 Types of oxy-acetylene gas used e.g.(high and low pressure system).





6.5 Installations of welding equipment.





6.6 Welding nozzles.





6.7 Defects of oxy-acetylene welding  – slag  inclusion, porosity, crack,  lack of penetration, etc and  their remedies.











6:3:1 Identification of equipment.



6:4:1 Demonstration of  how to use high and low pressure  system.



6:5:1 Demonstration of how to assemble welding equipment.



6:6:1 Demonstration of  how to install  welding equipment.

6:7:1 Identification of weld defects.

Auto body repair work

(a) Minor auto body repair.

































(b) Major auto body repair.

7.1 Types of auto body

(i) integral body;

(ii) composite body .



7.2 Basic methods of straightening auto body: aligning the metal with power jack,  pulling the metal with sledge hammer, using pre- bar, pulling the metal with pull

taps. Heat-shrinking the metal to bring  the metal back to its original shape.



7.3 Tools used in-minor repairs- hammers, hand dollies, spoons,  spanners, screw drivers, etc.





7.4 Major body sections e.g. front  engine compartment,  passenger section, rear section



7.5 Basic alignment principle.



7.6 Quarter panel cutting.









7.7 Light weight panels.



7.8 Damaged vehicle alignment.

7:1:1 Identification of integral and composite bodies.



7:2:1 Identification of auto- body repair tools.

7:2:2 Identification of heat shrinking tools.







7:3:1 Demonstration of  how to use the  tools in carrying  out minor repairs.

7:4:1 Identification of major body sections.







7:6:1 Identification of quarter panel and demonstration of how to cut it.



7:7:1 Repair and aligning of body sections.

8.

Aluminum panel repair.

8.1 Steps involved in aluminum  panel repair.

8.2 Repair and alignment of damaged aluminum panel.

8.3 Aluminum deck lid repair.

8:2:1 Demonstration of how to repair and align aluminum panel.

8:3:1 Aluminum deck lid repair procedure

9.

Plastic repairs.

9.1 Precautions while working with plastics.



9.2 Types of plastic resins (thermosetting and thermoplastic).



9.3 Repair of plastic parts by melting.



9.4 Introduction to glass fibre panel repair.







9:2:1 Identification of plastics.





9:3:1 Demonstration of  how to repair  plastics parts by melting.

10.

Spray painting:

(a) Spray gun and accessories.





















(b) Surface preparation.







(c) Type of paints.











(d) Metallic paint.










10.1 Spray gun – pressure feed gun siphon and gravity gun.



10.2 Spray gun parts – air cap, fluid needle, air valve, trigger gun, body, cup, etc.



10.3 Precautions in the use of spray gun.



10.4 Manufacturer’s maintenance guide.



10.5 Preparation of surfaces for spray painting.









10.6 Paints used on auto bodies cellulose synthetic paint, enamel paint, acrylic, metallic paints, etc.

10.7 Importance of manufacturer’s paint code.

10.8 Special paints and their importance.



10.9 Variable agents (flakes and pigments).



10.10 Metallic spray techniques (wet and dry spray).



10:1:1 Identification of pressure feed gun, siphon gun and gravity gun.

















10:5:1 Preparation of  metal surfaces for  spray painting.



10:6:1 Identification of   paints used on auto bodies.
















10:10:1 Demonstration

 of metallic  spray  techniques.

11.

Auto body workshop business.

11.1 Factors to consider in locating auto body repair shop – capital,  accessibility, land, etc.



11.2 List of tools and equipment.







RECOMMENDED READING LIST



1.  The repair of vehicle bodies by Alan Robinson (3rd Edition).



2.  Fundamentals of vehicle body work by J. Fairbrother.



3.  Practical welding (The motivate series Mac-Milan texts for Industrial Vocational and Technical Education) by S. Gibson.



4.  Fundamentals of motor vehicle technology, chassis and body electronics (5th Edition) Book 1, 2, and 3 by Hilliers V. A. W. and David R. Rogers.



5.  Bodywork Maintenance and repair including interiors by Paul Browne.



6.  Automotive encyclopedia by Good heart-Willcox.



7.  Auto body repair and repainting by Bill Tobold.
