## MAP WORK

A map is a scale representing the earth’s surface on a flat material.For example a piece of paper, wall, clothes and a piece of wood.

Map interpretation is the ability to translate the symbols and signs on the map ordinary language by industries the features that they represent.

COMPONENTS /QUALITIES/ESSENTIALS OF A GOOD MAP

COMPONENTS /QUALITIES/ESSENTIALS OF A GOOD MAP

A map is good if it contains all the essentials of maps, therefore the essentials are good qualities of maps.

The essentials of a good map are:

1) Key.

Used to interpret symbols and signs found on a map.

For example.

2) Title

Used to show what’s map is all about. This is the heading of the map. It can appear on top of the map or any where else

3) North direction

This is an indication of the north direction. It shows where north is and by knowing north one can know the direction and bearing of the place.

N

N

4) Margin

This is a boundary or limit around the map. It gives or shows the reader and interpreter the end of the map.

5) Publisher and date publication

This shows when the map was produced and a publisher.

6) A scale

It shows the relationship between map distance and the actual ground distance for example 1cm to 10km means one centimeter on the map represents ten kilometers on the ground

7) Latitude and Longitude / Grid reference .

5) Publisher and date publication

This shows when the map was produced and a publisher.

6) A scale

It shows the relationship between map distance and the actual ground distance for example 1cm to 10km means one centimeter on the map represents ten kilometers on the ground

7) Latitude and Longitude / Grid reference .

It used to locate the place on the map. Forexample the map of Tanzania is located at latitude 6°00′ south of the equator and longitude 35°00′ east of Greenwich meridian.

TYPES OF MAPS

The classification of maps are based on the purpose for which each map is drawn. Therefore map.can be categorized into three types as follows:

i) Sketch map

ii) Atlas map/ wall maps

iii) Topographical maps

i) Sketch maps

A map drawn from observation (rather than from exact measurements) and representing the main features of an area.

ii) Atlas map/ wall maps

A collection of different maps that have been bound together in one volume to form a book. These maps are usually drawn to scales example shows town and cities, hills, mountains, valleys, forests, countries, etc.

iii) Topographical maps.

Shows selected physical and human features in an area and their positions on the ground for example hills, village, mountains, lakes, ponds, rivers

MAP SCALE

i) Sketch map

ii) Atlas map/ wall maps

iii) Topographical maps

i) Sketch maps

A map drawn from observation (rather than from exact measurements) and representing the main features of an area.

ii) Atlas map/ wall maps

A collection of different maps that have been bound together in one volume to form a book. These maps are usually drawn to scales example shows town and cities, hills, mountains, valleys, forests, countries, etc.

iii) Topographical maps.

Shows selected physical and human features in an area and their positions on the ground for example hills, village, mountains, lakes, ponds, rivers

MAP SCALE

Is the relationship or ratio between map distance and actual ground distance.

Scale = map distance

Ground (actual) distance.

Ground (actual) distance.

TYPES OF SCALE.

We can classify the scale according to the size in our criteria. There are three types of scales;

a) Large scale.

a) Large scale.

They are used to present information on small areas for example a map of village buildings and farms. The map size involves all numbers less than 1:25000

I.e. 1:10000 and 1:5000

Characteristics of large scale.

i) It has smaller numbers in the denominator.

ii) It shows features clearly

iii) It contains geographical details.

b) Medium scale.

b) Medium scale.

They are used to represent medium details shown on the map.

Map size involves numbers between 1:25000 to 1:250000 i.e. 1:50,000 and 1:100,000. Example of a map that can be drawn using medium scale is a map of a district, region, city etc.

c) Small scale.

They are used to present information that is long.

This type of scale covers a big area with less detail. For example a map of a country, continent or world. May involve numbers between 1 : 500,000 to

1 : 1000,000

1 : 1000,000

Characteristics of small scale.

i) It has the largest denominator.

ii) Contains a lot of geographical information.

iii) It does not show geographical features clearly.

WAYS USED TO EXPRESS MAP SCALE.

i) As a statement.

Refers to th

e scale which is expressed in terms of words or explanation. For example one centimeter on a map is equivalent to 10 centimeters on the ground.

e scale which is expressed in terms of words or explanation. For example one centimeter on a map is equivalent to 10 centimeters on the ground.

ii) Linear scale

Is called plain or graphic scale. This is a line which is divided into two parts. The primary division and secondary division. The secondary are expressed in meters and placed on the left side from zero and primaries are expressed in kilometers and placed on the right side from zero.

iii) Representative fraction (RF) scale

Is written as 1 or ratio 1 : 50,000

50,000

The distance on a map is expressed as fraction of the actual distance on the ground.

Therefore, RF scale = map distance

Ground distance

– That is- the top number (numerator) represents the map distance on the ground and is usually more than 1.

IMPORTANCE OF SCALE ON THE MAP

a) Scale help to calculate area of a map

b) It enable us to calculate distance on a map

c) Scale shows the relationship between map distance and the actual ground distance

d) Scale help us to enlarge and reduce the area on a map or the whole map

e) Scale can be used to calculate the vertical exaggeration on a map

f) Scale is used to calculate the gradient on a map

iii) Representative fraction (RF) scale

Is written as 1 or ratio 1 : 50,000

50,000

The distance on a map is expressed as fraction of the actual distance on the ground.

Therefore, RF scale = map distance

Ground distance

– That is- the top number (numerator) represents the map distance on the ground and is usually more than 1.

IMPORTANCE OF SCALE ON THE MAP

a) Scale help to calculate area of a map

b) It enable us to calculate distance on a map

c) Scale shows the relationship between map distance and the actual ground distance

d) Scale help us to enlarge and reduce the area on a map or the whole map

e) Scale can be used to calculate the vertical exaggeration on a map

f) Scale is used to calculate the gradient on a map

Distinguish and explain signs from symbols

SYMBOLS | SIGNS |

1. Symbols normally look like the features they represent. e.g. church | Signs do not look like the features they represent. e.g. height in meters •1121 -Coffee, Sisal, tea plantations |

2. Most symbols used in map are pictorial | While signs are not pictorial |

2) QUANTITATIVE INFORMATION ON MAPS

A) MEASURING DISTANCE ON THE MAP

A) MEASURING DISTANCE ON THE MAP

Distance is the length of an elongated features on the earth’s surface such as road, railway, river etc.

How to measure distance.

In order to obtain distance of any feature on the map, consideration should be made on whether the distance to be measured is straight or curved.

Straight distance

For all straight distances a ruler is used to obtain the distance directly from the topographical map given.

Curved distance.

It becomes difficult to obtain curved distance of the features by the use of a ruler directly from the topographical map when the area is inclined. In this case the following devices can be used:-

I. A pair of divider.

A pair of divider is commonly

used to measure the distance. You should start by breaking the length by using a pair of dividers then transfer some of the already drawn straight lines. Then transfer the measured line to the linear scale or ruler for calculation to get the actual distance.

used to measure the distance. You should start by breaking the length by using a pair of dividers then transfer some of the already drawn straight lines. Then transfer the measured line to the linear scale or ruler for calculation to get the actual distance.

II. A piece of a string.

Slowly measure the distance by a piece of string along a given length then transfer it to a linear scale or ruler for actual calculation of the distance.

20cm map distance

Scale distance= map distance

Actual distance

½ km ½ x 2 = 240km

1:50000

1/50000 =20cm

100000 = 20cm

50000 x

=10km.

- A piece of strip paper

Slowly lay a piece of paper along a given length then break your lengths into short segments then transfer to the linear scale for measuring and calculation.

MEASURING AREAS ON A MAP/CALCULATE AREA OF REGULAR IRREGULAR

Area size refers to the bigness or smallness of an area on the earth’s surface i.e. the bigness or smallness of earth’s surface from topographical map consideration should be made whether the area is regular or not.

Exercise

1) To state the following.

a) map is a scale representing the earth’s surface on a flat material

b) map reading refers to a scale reading which is obtained from recognizing or identifying signs and symbols that are used on a map.

c) Scale is the relationship or ratio between map distance and actual ground.

d) Contour is a line drawing on a map which shows the area at the same point.

2) Why do we study maps?

i) People use them to reach their directions.

ii) Builders use maps to build new roads.

iii) Maps are used in conducting various geographical researches.

iv) Maps are useful in military activities.

v) Maps are useful in describing the features on the earth’s surface.

3) To state the way of expressing scale.

i) Statement scale; Refers to the scale which is used or expressed in terms of words for example 1cm on the map is equivalent to 10 km on the ground.

ii) Linear scale; Is called plain, it has the primary division and secondary division.

4) What is the importance of a scale?

– It helps to calculate area of a map

– It enable us to calculate distance on a map

– Scale help us to enlarge and reduce the area on a map

– It helps to calculate area of a map

– It enable us to calculate distance on a map

– Scale help us to enlarge and reduce the area on a map

5) List at least 3 methods of calculating the linear distance of an object.

i) A Pair of dividers

ii) A piece of paper

iii) A piece of string.

6)The distance of the road is 36cm from Lindi to Nachingwea, convert the distance in kilometers if the scale used is 1:100000

Solution

Distance =36cm

Scale =1:100, 000

1km =100,000cm

1 Km= x

Hence, 1 cm= 1 km

(after cross multiplication):

Therefore 1cm= 1km

36cm= x

(cross multiplication)

Hence, 1 cm= 1 km

(after cross multiplication):

Therefore 1cm= 1km

36cm= x

(cross multiplication)

1x =36km

X=36 the distance is 36km.

Therefore, the distance on the ground from Lindi to Nachingwea is 36km.

b)From the above convert the same distance in km if the scale is changed to 1:50000

Solution

Distance=36cm

Scale =1:50000 1km =100,000cm

x = 50, 000cm

x = 50, 000cm

(cross multiplication)

=0.5km

Therefore the distance in Kilometers is 0.5km

Therefore the distance in Kilometers is 0.5km

REGULAR SHAPE

These are areas with definite shapes such as squares, triangles etc. Their total perimeters or areas are obtained by mathematical formula i.e. length x width, side x side etc.

IRREGULAR SHAPE

These are areas with indefinite shapes such as lakes, farms, ponds etc where these areas can be obtained by any of the following three methods;

a) Square method

b) Strip method

b) Strip method

c) Geometrical method

SQUARE METHOD

This is the most accurate and most widely method used.

Square methods are normally used as follows;

a) Count all full squares that are complete

b) Count incomplete squares and divide them by 2

c) Add them with the full squares to obtain the total area in km2

METHODS USED TO SHOW OR LOCATE POSITIONS OF A PLACE ON A MAP.

The following are major methods used to show positions of a place on a map.

i) Grid reference.

ii) Place name

iii) Bearing and compass direction.

iv) Latitude and longitude.

Place name.

You can locate the position of a place by where the features are found i.e. Mbeya, Dodoma, Mtwara.

Grid reference.

Grid reference is a network of vertical lines and horizontal lines on a map. Vertical lines whose numbers increases towards the east are called easting. Horizontal lines whose numbers increase towards the north is known as Northings. Where horizontal lines and vertical lines meet or cross each other they form a square known as grid square. (G.S). A grid reference point is written inform of six digits starting with three digits of Eastings then three digits of nothings’

To write down the grid reference of point A, B, C, D.

A=12006

B =130065

C =140067

D=14003.

LOCATION AND POSITION:

LOCATION AND POSITION:

COMPASS BEARING AND DIRECTION.

Compass direction is divided into

a) 4 cardinal points

b) 8 cardinal points

c) 16 cardinal points

4 cardinal points

8 cardinal points.

16 cardinal points

HOW TO FIND DIRECTION OF A PLACE ON A MAP.

1) Identify them due to points on the given map. Points may be given by using grid reference points, place name or letter.

2) Draw a straight line connecting the two points

3) Mark the major four cardinal points at the starting point with the word from.

4) Now look at the question asked then provide your answer.

What is the direction of point A from B. the direction of point A is NW.

COMPASS BEARING.

Bearing are directions which measure degrees clockwise from north. They are written in three figures i.e. 0900, 0450

HOW TO FIND BEARING ON THE MAP.

1) Identify the grid reference points given on the maps.

2) Draw a straight line connecting the two points

3) Draw the major four cardinal lines at the starting

4) Now look at the question asked use a protector to measure degree clockwise from north up to the line joining the two points.

Provide your answer in degrees i.e. what is the bearing of point A from B

BEARING.

a) Forward bearing

b) Backward bearing

a) FORWARD BEARING

Is a bearing into a subject.

Procedures to calculate forward bearing

1) i. Identify the two points.

ii. Join them with a straight lines

iii. Draw north direction on a second point.

iv.Measure the angle by using a protector.

v. State the bearing in terms of degrees of the direction.

i.e. Find the formed bearing of Moa from Midland.

B=1350 SE

Find the bearing of Mbezi to Ubungo.

The bearing of Mbezi to Ubungo is 1350 SE

b) Backward bearing.

Is the opposite of forward bearing, it’s taken from the object to the observer while forward bearing is taken from observer to the object.

How to determine the back bearing.

i) Find forward bearing.

ii) Mark the cardinal point north direction of the opposite point

iii) Find the bearing of the observer along the straight line principally to determine the back bearing= FB +OR- 1800 BB= FB +1800 IF FB<1800BB=FB-180+FB>1800

EXERCISE

Scale conversion

a)To change statement to R.F scale 1cm represents 60km

Soln

1km=100000cm

60km= x

1:6000000

R.F scale = 1:6000000

b)One centimeter represents 0.75km

Soln. 1km = 100000 cm

100000 x 0.75

=75000

1:75000 R.F scale = 1:75000

c) One centimeter representing two kilo meters

Soln

1km =100000

1km =100000

100000 x 2 = 200000

1:200000 R.F scale =1:200000

IMPORTANCE OF THE USE OF MAPS

a) People use them to reach their directions

b) Maps are used to describe the features of the earth

c) Builders are maps to plan the best use of the land

d) Road constructors use maps to construct new roads

e) Maps are useful in military activities

f) Maps are used in conducting various

g) Maps are used in conducting various geo

graphical researches

IMPORTANCE OF THE USE OF MAPS

a) People use them to reach their directions

b) Maps are used to describe the features of the earth

c) Builders are maps to plan the best use of the land

d) Road constructors use maps to construct new roads

e) Maps are useful in military activities

f) Maps are used in conducting various

g) Maps are used in conducting various geo

graphical researches
